MasterTow

Weight icon-kg
Up to 20,000kg

Powerful electric tow tugs to effortlessly move up to 20,000kg with total control, with pedestrian operated, remote control and automated options available…

Video Player is loading.
Current Time 0:00
Duration -:-
Loaded: 0%
Stream Type LIVE
Remaining Time -:-
Â
1x
    • Chapters
    • descriptions off, selected
    • subtitles off, selected

      The MasterTow range of powerful, easy-to-use electric tow tugs, is ideally suited to towing loads weighing up to 20,000kg. The range uses its own weight to deliver consistent traction, enabling the effortless movement of loads both inside, outside and on slopes.   

      Boasting intuitive operator controls and safety built-in as standard, the range provides operators with complete control when moving heavy loads. With a simple and effective coupling system, the MasterTow range guarantees load security and is perfectly suited to moving individual and multiple loads linked together.  

      Take advantage of innovative technology with Electric Steer (ES), available from the TOW600 ES upwards. With Electric Steer, benefit from instantaneous steering and added performance in adverse conditions. The MasterTow range is available with Remote Control, for maximum operator visibility, and Autonomous (AGV) solutions for maximum ROI, safety and efficiency. 

      MasterTow Key Features

      You need a high quality, durable electric tow tug that doesn’t compromise on safety. The MasterTow range is packed full of features that maximise operator safety when moving wheeled loads.

      Staff safety - icon

      Safety  

      • Audible horn, flashing light beacon, and emergency stop  
      • Multiple speed settings for complete control 
      • Machine crawl coupling assist available for easy connection 
      Performance - icon

      Performance 

      • Powerful performance delivers high torque even at low speeds 
      • Optimised weight distribution for guaranteed traction 
      • Start, move and stop movement on slopes 
      Scalable pulling power - icon

      Power  

      • High performance, interchangeable batteries for 24/7 operation 
      • Optional Battery Protection System maximises battery life 
      • Lithium batteries available 
      Secure coupling - icon

      Connection 

      • Easy and universal coupling options 
      • Lockable couplings to keep loads secure 
      • Variety of coupling options available 

      Explore the MasterTow Range

      With a variety of machines able to move loads weighing up to 20,000kg, the MasterTow range provides effective material handling solutions to drive safety and operational efficiency.

      9 Results

      TOW200

      Download technical information
      Request a quote
      • Load capacity 2000 kg
      • Maximum slope 10 degrees
      • Max distance per charge (standard battery) 16.6 km
      • Charge time (external charger) 5.5h

      TOW300

      Download technical information
      Request a quote
      • Load capacity 3000 kg
      • Maximum slope 10 degrees
      • Max distance per charge (standard battery) 11.8 km
      • Charge time (external charger) 5.5h

      TOW600

      Download technical information
      Request a quote
      • Load capacity 6000 kg
      • Maximum slope 10 degrees
      • Max distance per charge (standard battery) 8.5 km
      • Charge time (external charger) 7.5h

      TOW600 ES

      Download technical information
      Request a quote
      • Load capacity 6000 kg
      • Maximum slope 10 degrees
      • Max distance per charge (standard battery) 8.5 km
      • Charge time (external charger) 7.5h

      TOW800 ES

      Download technical information
      Request a quote
      • Load capacity 8000 kg
      • Maximum slope 10 degrees
      • Max distance per charge (standard battery) 6.5 km
      • Charge time (external charger) 7.5h

      TOW1000 ES

      Download technical information
      Request a quote
      • Load capacity 10000 kg
      • Maximum slope 8 degrees
      • Max distance per charge (standard battery) 10.2 km
      • Charge time (external charger) 7.5h

      TOW1200 ES

      Download technical information
      Request a quote
      • Load capacity 12000 kg
      • Maximum slope 8 degrees
      • Max distance per charge (standard battery) 8.6 km
      • Charge time (external charger) 7.5h

      TOW1500 ES

      Download technical information
      Request a quote
      • Load capacity 15000 kg
      • Maximum slope 8 degrees
      • Max distance per charge (standard battery) 6.9 km
      • Charge time (external charger) 7.5h

      TOW2000 ES

      Download technical information
      Request a quote
      • Load capacity 20000 kg
      • Maximum slope 8 degrees
      • Max distance per charge (standard battery) 5.9 km
      • Charge time (external charger) 8.5h

      Download technical datasheet

      Safety & machine options

      With an array of features and coupling options available, the MasterTow can be used to move single loads or multiple loads linked together in a train or milk run system.

      Connection
      MasterTow tow pin coupling

      Tow pin

      Works with a range of drawbars allowing easy and secure connection every time.

      MasterTow box coupling

      Box coupling

      A perfect solution – and a secure connection - for use on rough surfaces.

      MasterTow fifth wheel coupling

      Fifth wheel

      Delivers precise movements when pushing alongside box coupling.

      MasterTow towing arm coupling

      Towing arm

      Create a secure connection to existing pin systems.

      MasterTow tow ball coupling

      Tow ball

      A simple and robust connection to 50mm ball hitch couplings.

      Custom coupling - icon

      Custom couplings

      Need something different? We can design custom couplings to suit your application.

      Use of a MasterMover electric tug has enabled us to use a bit of the mill layout for vastly improved production ability and better, faster customer service – space that was previously set aside for forklift movement.

      Benefits of MasterTow Tow Tugs

      When you need a reliable and flexible solution to move heavy loads, the MasterTow range of electric tow tugs delivers every time.

      Weight capacity - icon

      Safe movement of loads weighing up to 20,000kg

      Licence free operation - icon

      License-free operation

      Zero emissions - icon

      Zero emissions

      Compact - icon

      Compact machines for tight spaces

      Interchangeable battery - icon

      Interchangeable battery systems for 24/7 operation

      Eliminate manual handling - icon

      Eliminate manual handling

      All terrain - icon

      Suitable for indoor and outdoor use

      Secure coupling - icon

      Easy and secure couplings

      Your Questions, Answered – FAQs

      What technology options are available on the MasterTow range?

      Remote Control: Excellent visibility for easy positioning, with control at the fingertips of the operator.

      Wireless AutoSteer: Movement using line follow navigation with speed controlled by the operator via remote control.

      Line follow: Autonomous operation using line follow navigation with optional barcode scanning for automatic speed adjustment, best-in-class safety systems reduce risk.

      Can you use electric tow tugs outside?

      Yes, MasterMover electric tow tugs can be used outside. Built with durability in mind, the MasterTow range delivers consistent traction and performance on uneven surfaces and rough floors. Purpose-built for industrial environments, the MasterTow range can be used inside, outside and on slopes.

      Can the MasterTow range push and pull?

      Yes, the MasterTow range can push and pull. The design of an electric towing machine means that pulling performance is greater than pushing performance, but with solutions capable of moving up to 20,000kg, our team can advise you on which model is best for your application.

      What is the maximum speed of the MasterTow range?

      With the Two Speed Selector switch, ‘Tortoise’ mode enables you to maximise control and operate the machine at a slower speed setting of 1.2kph. In the faster ‘Hare’ setting, the machine’s speed is 3kph. Machines can be set with custom speed settings where required, with a maximum programmable speed of 6kph.

      How far can the MasterTow range travel on one charge?

      Battery performance varies from model to model and is influenced by load weight, battery capacity, environmental conditions and usage. Individual battery performance data for each model can be found on the Technical Specification Sheets available for download.

      How does the MasterTow range connect to loads?

      A range of coupling options are available across the range that maximise performance, security and safety. The tow pin coupling offers a plug-and-play solution perfectly suited to connecting to a range of drawbars.

      Can the MasterTow range work on slopes?

      Yes, the MasterTow range can work safely on slopes. When it comes to electric tugs and tows, it’s important to understand that for every degree of slope involved, the maximum load capacity of the machine is reduced, just as pushing a car on the level requires less force than on a slope.

      Therefore, if the weight of the load is already close to the maximum capacity of the machine, a more powerful machine may be needed to move the load on a slope. We carry out a full evaluation of your application to ensure any machine is suited to your needs.
