MasterTow

Weight icon-kg
Up to 20,000kg

Powerful electric tow tugs to effortlessly move up to 20,000kg with total control, with pedestrian operated, remote control and automated options available…

The MasterTow range of powerful, easy-to-use electric tow tugs, is ideally suited to towing loads weighing up to 20,000kg. The range uses its own weight to deliver consistent traction, enabling the effortless movement of loads both inside, outside and on slopes.   

Boasting intuitive operator controls and safety built-in as standard, the range provides operators with complete control when moving heavy loads. With a simple and effective coupling system, the MasterTow range guarantees load security and is perfectly suited to moving individual and multiple loads linked together.  

Take advantage of innovative technology with Electric Steer (ES), available from the TOW600 ES upwards. With Electric Steer, benefit from instantaneous steering and added performance in adverse conditions. The MasterTow range is available with Remote Control, for maximum operator visibility, and Autonomous (AGV) solutions for maximum ROI, safety and efficiency. 

MasterTow Key Features

You need a high quality, durable electric tow tug that doesn’t compromise on safety. The MasterTow range is packed full of features that maximise operator safety when moving wheeled loads.

Staff safety - icon

Safety  

  • Audible horn, flashing light beacon, and emergency stop  
  • Multiple speed settings for complete control 
  • Machine crawl coupling assist available for easy connection 
Performance - icon

Performance 

  • Powerful performance delivers high torque even at low speeds 
  • Optimised weight distribution for guaranteed traction 
  • Start, move and stop movement on slopes 
Scalable pulling power - icon

Power  

  • High performance, interchangeable batteries for 24/7 operation 
  • Optional Battery Protection System maximises battery life 
  • Lithium batteries available 
Secure coupling - icon

Connection 

  • Easy and universal coupling options 
  • Lockable couplings to keep loads secure 
  • Variety of coupling options available 

Explore the MasterTow Range

With a variety of machines able to move loads weighing up to 20,000kg, the MasterTow range provides effective material handling solutions to drive safety and operational efficiency.

Filters applied
    48 Results

    Custom solution available, contact us here.

    TOW200

    Download technical information
    Request a quote
    • Load capacity 2000 kg
    • Maximum slope 10 degrees
    • Max distance per charge (standard battery) 16.6 km
    • Charge time (external charger) 5.5h

    TOW300

    Download technical information
    Request a quote
    • Load capacity 3000 kg
    • Maximum slope 10 degrees
    • Max distance per charge (standard battery) 11.8 km
    • Charge time (external charger) 5.5h

    TOW600

    Download technical information
    Request a quote
    • Load capacity 6000 kg
    • Maximum slope 10 degrees
    • Max distance per charge (standard battery) 8.5 km
    • Charge time (external charger) 7.5h

    TOW600 ES

    Download technical information
    Request a quote
    • Load capacity 6000 kg
    • Maximum slope 10 degrees
    • Max distance per charge (standard battery) 8.5 km
    • Charge time (external charger) 7.5h

    TOW800 ES

    Download technical information
    Request a quote
    • Load capacity 8000 kg
    • Maximum slope 10 degrees
    • Max distance per charge (standard battery) 6.5 km
    • Charge time (external charger) 7.5h

    TOW1000 ES

    Download technical information
    Request a quote
    • Load capacity 10000 kg
    • Maximum slope 8 degrees
    • Max distance per charge (standard battery) 10.2 km
    • Charge time (external charger) 7.5h

    TOW1200 ES

    Download technical information
    Request a quote
    • Load capacity 12000 kg
    • Maximum slope 8 degrees
    • Max distance per charge (standard battery) 8.6 km
    • Charge time (external charger) 7.5h

    TOW1500 ES

    Download technical information
    Request a quote
    • Load capacity 15000 kg
    • Maximum slope 8 degrees
    • Max distance per charge (standard battery) 6.9 km
    • Charge time (external charger) 7.5h

    TOW2000 ES

    Download technical information
    Request a quote
    • Load capacity 20000 kg
    • Maximum slope 8 degrees
    • Max distance per charge (standard battery) 5.9 km
    • Charge time (external charger) 8.5h

    Download technical datasheet

    Safety & machine options

    With an array of features and coupling options available, the MasterTow can be used to move single loads or multiple loads linked together in a train or milk run system.

    Connection
    MasterTow tow pin coupling

    Tow pin

    Works with a range of drawbars allowing easy and secure connection every time.

    MasterTow box coupling

    Box coupling

    A perfect solution – and a secure connection - for use on rough surfaces.

    MasterTow fifth wheel coupling

    Fifth wheel

    Delivers precise movements when pushing alongside box coupling.

    MasterTow towing arm coupling

    Towing arm

    Create a secure connection to existing pin systems.

    MasterTow tow ball coupling

    Tow ball

    A simple and robust connection to 50mm ball hitch couplings.

    Custom coupling - icon

    Custom couplings

    Need something different? We can design custom couplings to suit your application.

    Power
    MasterTow high capacity battery

    High-capacity batteries

    Increased capacity batteries for longer performance.

    MasterTow lithium battery

    Lithium battery options

    Power when you need it, enabling opportunity charging for demanding applications.

    MasterTow battery protection system

    Battery protection system

    Maximise your battery service life by preventing battery damage.

    MasterTow internal charger

    Internal onboard chargers

    Our onboard chargers provide flexible charging when you need it.

    MasterTow external charger

    External charger

    Guarantees fast, optimised charging for fixed locations.

    Safety
    MasterTow two speed selector switch

    Two speed selector switch

    Adjustable speed settings at your fingertips.

    MasterTow safety light and bleeper

    Safety light beeper

    Maximise safety when moving loads through congested areas.

    MasterTow emergency stop button

    Emergency stop

    Allows you to immediately stop the machine.

    MasterTow anti-crush button

    Anti-crush button

    Protect operators and maximise operator safety when moving loads.

    MasterTow warning horn

    Warning horn

    Perfect for congested areas, alert pedestrians when moving loads.

    MasterTow automatic tiller cut off

    Automatic cut-off

    Preventing accidental operation of the machine.

    Control
    MasterTow remote control

    Remote control

    Excellent visibility for easy positioning, with simple controls.

    MasterTow wireless auto steer

    Wireless AutoSteer

    Follow predetermined routes, with operator in control of movement.

    MasterTow line follow

    Line follow

    Autonomous operation using line follow navigation, for repeated movements.

    Use of a MasterMover electric tug has enabled us to use a bit of the mill layout for vastly improved production ability and better, faster customer service – space that was previously set aside for forklift movement.

    Benefits of MasterTow Tow Tugs

    When you need a reliable and flexible solution to move heavy loads, the MasterTow range of electric tow tugs delivers every time.

    Weight capacity - icon

    Safe movement of loads weighing up to 20,000kg

    Licence free operation - icon

    License-free operation

    Zero emissions - icon

    Zero emissions

    Compact - icon

    Compact machines for tight spaces

    Interchangeable battery - icon

    Interchangeable battery systems for 24/7 operation

    Eliminate manual handling - icon

    Eliminate manual handling

    All terrain - icon

    Suitable for indoor and outdoor use

    Secure coupling - icon

    Easy and secure couplings

    Your Questions, Answered – FAQs

    What technology options are available on the MasterTow range?

    Remote Control: Excellent visibility for easy positioning, with control at the fingertips of the operator.

    Wireless AutoSteer: Movement using line follow navigation with speed controlled by the operator via remote control.

    Line follow: Autonomous operation using line follow navigation with optional barcode scanning for automatic speed adjustment, best-in-class safety systems reduce risk.

    Can you use electric tow tugs outside?

    Yes, MasterMover electric tow tugs can be used outside. Built with durability in mind, the MasterTow range delivers consistent traction and performance on uneven surfaces and rough floors. Purpose-built for industrial environments, the MasterTow range can be used inside, outside and on slopes.

    Can the MasterTow range push and pull?

    Yes, the MasterTow range can push and pull. The design of an electric towing machine means that pulling performance is greater than pushing performance, but with solutions capable of moving up to 20,000kg, our team can advise you on which model is best for your application.

    What is the maximum speed of the MasterTow range?

    With the Two Speed Selector switch, ‘Tortoise’ mode enables you to maximise control and operate the machine at a slower speed setting of 1.2kph. In the faster ‘Hare’ setting, the machine’s speed is 3kph. Machines can be set with custom speed settings where required, with a maximum programmable speed of 6kph.

    How far can the MasterTow range travel on one charge?

    Battery performance varies from model to model and is influenced by load weight, battery capacity, environmental conditions and usage. Individual battery performance data for each model can be found on the Technical Specification Sheets available for download.

    How does the MasterTow range connect to loads?

    A range of coupling options are available across the range that maximise performance, security and safety. The tow pin coupling offers a plug-and-play solution perfectly suited to connecting to a range of drawbars.

    Can the MasterTow range work on slopes?

    Yes, the MasterTow range can work safely on slopes. When it comes to electric tugs and tows, it’s important to understand that for every degree of slope involved, the maximum load capacity of the machine is reduced, just as pushing a car on the level requires less force than on a slope.

    Therefore, if the weight of the load is already close to the maximum capacity of the machine, a more powerful machine may be needed to move the load on a slope. We carry out a full evaluation of your application to ensure any machine is suited to your needs.

    Sectors we work in

    Ready to Unlock Safer Operations?

    Are you looking to improve safety and efficiency in your operations? Contact us to discover how you could transform your processes to enhance efficiency and maximise workplace safety with an electric tug or electric tow tug.
